socomec FUSERBLOC User Manual

ON
O
OFF
90°
I
1.57 in
40 mm
1.10 in
28 mm
Ø 1.45 in
Ø 37 mm
4 Ø 0.27 in
4 Ø 7 mm
0.76
±.079
in
19,5
±2
mm
1.57 in
40 mm
1.10 in
28 mm
Ø 1.22 to 1.45 in
Ø 31 à 37 mm
4 Ø 0.27 in
4 Ø 7 mm
O
OFF
90°
65°
ON I
TEST
L = X +1.10 in
L = X + 28 mm
L
0.59 in
15 mm
X min. 0.78 in / 20 mm
X max. 9.05 in / 230 mm
0.76 in
19,5 mm
L = X - 1.71 in
L = X - 43,5 mm
X
L
0.76 in
19,5 mm
=
=
min. 0.78 in / 20 mm
max. 1.18 in / 30 mm
1.22 in / 31 mm
1.41 in / 36 mm
63A A2-A3
125/160/200 compact
1x
3x
max. Ø 0.23 in / Ø 6 mm
min. Ø 0.19 in / Ø 5 mm
=
=
J
U
J1
K
max. Ø 0.31 in / Ø 8 mm
min. Ø 0.19 in / Ø 5 mm
3x
or
ou
o
1
2
1 1
Padlocking the handle - Front and Side operation
Cadenassage de la poignée - Commande frontale et latérale
Bloqueable por candados - Mando frontal y lateral
Shaft length / Longueur d’axe / Longitud del eje
Shaft padlocking / Cadenassage de l’axe / Bloqueo con condado del eje
IF NECESSARY / SI NECESSAIRE / SI NECESARIO
Calibre (A)
Rating (A)
Taille fusible
Fuse size
Taille boîtier
Frame size
J (3p) J (4p) J1 K U X min. X max.
in mm in mm in mm in mm in mm in mm in mm
32 A1 11 1.06 27 2.12 54 1.77 45 4.17 106 0.23 6 3.93 100 5.70 145
50 14 x 51 11 1.06 27 2.12 54 1.77 45 4.17 106 0.23 6 3.93 100 5.70 145
63 A2-A3 12 1.26 32 2.52 64 1.96 50 4.17 106 0.21 5,4 5.47 139 5.70 145
63 00C 12 1.26 32 2.52 64 1.96 50 4.17 106 0.21 5,4 5.47 139 5.70 145
100 A4 13 1.41 36 2.83 72 2.12 54 5 127 0.21 5,4 5.47 139 5.70 145
100/125 22 x 58 13 1.41 36 2.83 72 2.12 54 5 127 0.21 5,4 5.47 139 5.70 145
125/160/200 compact A3-A4 13a 1.41 36 2.83 72 2.12 54 4.11 130 0.21 5,4 5.47 139 5.70 145
125/160 00 13 1.41 36 2.83 72 2.12 54 5 127 0.21 5,4 5.47 139 5.70 145
160 A4-B1-B2 14 1.96 50 3.93 100 2.52 64 5.51 140 0.21 5,4 5.47 139 5.70 145
160 0 14 1.96 50 3.93 100 2.52 64 5.51 140 0.21 5,4 5.70 145 8.85 225
200 B1-B2 15 2.36 60 4.72 120 3.38 86 6.37 162 0.25 6,4 6.06 154 8.85 225
250 B1-B2-B3 15 2.36 60 4.72 120 3.38 86 6.37 162 0.25 6,4 6.06 154 8.85 225
250 1 15 2.36 60 4.72 120 3.38 86 6.37 162 0.25 6,4 6.06 154 8.85 225
315 B1-B2-B3 16 2.59 66 5.19 132 3.58 91 8.23 209 - - 9.05 230 11.81 300
400 B1-B2-B3-B4 16 2.59 66 5.19 132 3.58 91 8.23 209 - - 9.05 230 11.81 300
400 2 16 2.59 66 5.19 132 3.58 91 8.23 209 - - 9.05 230 11.81 300
A
Front operation
Commande frontale
Mando frontal
A
Front operation
Commande frontale
Mando frontal
Fixing
Fixation
Fijación
B
Side operation
Commande latérale
Mando lateral
B
Side operation
Commande latérale
Mando lateral
Front and side operation
Commande frontale et latérale
Mando frontal y lateral
Padlocking position
Position de cadenassage
Posicion con candado
Padlocking position
Position de cadenassage
Posicion con candado
Door drilling
Perçage de porte
Perforación de puerta
Door drilling
Perçage de porte
Perforación de puerta
OR / OU / O
max. Ø 0.31 in / Ø 8 mm
min. Ø 0.19 in / Ø 5 mm
1.57 in
40 mm
Ø 1.45 in
Ø 37 mm
4 Ø 0.27 in
4 Ø 7 mm
1.10 in
28 mm
Door drilling
Perçage de porte
Perforación de puerta
2 for IP 55 / 4 for IP 65
2 pour IP 55 / 4 pour IP 65
2 para IP 55 / 4 para IP 65
17.5 Ib-in
2 Nm
Pozidriv n°2
Used for IP65
Utilisé en IP65
Usado para IP65
2 for IP 55 / 4 for IP 65
2 pour IP 55 / 4 pour IP 65
2 para IP 55 / 4 para IP 65
17.5 Ib-in
2 Nm
Pozidriv n°2
Used for IP65
Utilisé en IP65
Usado para IP65
17.5 Ib-in
2 Nm
Pozidriv n°2
2 for IP 55 / 4 for IP 65
2 pour IP 55 / 4 pour IP 65
2 para IP 55 / 4 para IP 65
