Installation
4
INSTALLATION
This section assumes that the site meets the requirements.
Wall Mount Installation
The most common installation is the wall mount. In this installation, the
enclosure is mounted directly to a wall or uni-strut using suitable user-supplied
hardware.
Requirements
The anchoring system must be capable of sustaining 75 lb (34 kg). This
weight does not include the cables.
The cables are protected by use of conduit, which is metal, plastic, or flexible
cable grip strain relief.
An external power supply provides 12 Vdc to power the iSTAR Ultra SE.
If an ACM is powered by a different Power Supply Unit (PSU), the ACM Fail
trigger must be configured to alarm on failure.
For a UL installation the Power must be approved to UL-294 and/or UL-603.
To Wall Mount the Controller:
1. Carefully unpack the components. Software House recommends removing
the GCM and the ACM(s) from the enclosure before mounting. Use ESD
procedures while handling the boards.
2. Open the enclosure door and disconnect the grounding wire on the door.
3. Carefully lift the door off the hinges and place it on a padded surface.
4. Verify that the upper mounting screws (or equivalent) are in place on the
mounting site for the keyhole locations.
ELECTROSTATIC SENSITIVE DEVICES: Observe precautions for handling.
Before handling any internal components, discharge static electricity by holding a
grounding lug or non-painted grounded surface for three seconds.
Wear a grounding wrist strap and stand on a grounded static mat.
Reduce movement during installation to reduce static buildup.
Make sure work area is safeguarded.
Transport components in static-shielded containers.
Note: The outside of the ESD bags are not ESD protective.
Verify that all components, materials, and the installer are referenced to a common
ground.
NOTE
See Figure 1 on page 5 for the location of the keyhole slots, screws, and knockouts.
