Requirements
3
Types of Mounting
The iSTAR Ultra SE, and its components, can be installed in a wall mount
enclosure or in a separate rack mount enclosure.
REQUIREMENTS
Site Requirements
Ensure that the site is ready:
The iSTAR Ultra SE installation must be performed by a certified installer.
All Control Units of the iSTAR Ultra SE must be installed in a restricted
access protected area.
Non-limited power supply lines, lines capable of sourcing 5A or more, must
maintain (1/2 inch (1.3 cm)) spacing from limited power supply lines and
other signaling lines. Secure lines must be installed in accordance to local
and national electric codes.
The site must be approved and all wiring must comply with UL requirements
and other codes, as appropriate. Installation shall be in accordance with the
National Electric Code, ANSI/NFPA 70-1993.
Wall Mount Dimensions
Table 1 on page 3 lists the iSTAR Ultra SE Cabinet Wall Mount Dimensions
Environmental
Requirements
Table 2 on page 3 lists the iSTAR Ultra SE environmental requirements.
Table 1. Cabinet (Wall Mount Dimensions)
Item Dimension/Location
Weight 26.5 lb (12.02 kg)
Height 24.25 in. (61.6 cm)
Width 16.5 in. (41.9 cm)
Depth 4 in. (10.3 cm)
Upper Mounting
Holes
There are 2 upper keyhole type mounting holes that are spaced 14.25 in.
(36.2 cm) from each other. These two mounting holes are 7.125 in. (18.1
cm) from the enclosure center line.
Two Bottom
Mounting Holes
Directly below the upper mounting holes.
Table 2. Environmental Requirements
Status Range
Operation 32°F (0°C) to 120°F (49°C)
Storage 4° F (-20°C) to 158°F (70°C)
Altitude 6600 ft. (2000 m) maximum
Humidity 0 to 85%RH (Non-condensing)
