13
Operating Temperature: -31º F to 151º F (-35º C to 67º C)
Index of Protection: IP 65 (IEC 529)
Read Range: 1 to 5 inches depending on credential
technology and environment.
Note: Read range for credentials of
identical technologies may vary greatly
depending on the tuning and antenna
structure of each individual credential.
Standard Wiegand Output
including:
ID Pass-Through Option
Serial Number Read
Fixed Wiegand bit stream option
SmartFrame® encrypted MIFARE Sector
read and conversion to Wiegand. Consult
your Software House representative for
available reconfiguration cards for your
reader.
8-bit burst Wiegand PIN code (Model
SWH-4200 only)
PIN-on-card featured (Model SWH-4200
only)
Upgrade Complete upgrade capability using RS485
port for reflashing of internal ROM.
RS485 output option Available for compatible controllers.
