MODEL SWH-4X00 TECHNICAL
SPECIFICATIONS
Cable Recommendations: 4 core (minimum), shielded, 22 AWG
(minimum) cable.
Connectors: 12 position, 3.5 mm Screw Terminals -
Plug-In
Certifications: FCC Part 15, CE and UL 294
Open Standards
Compliance:
ISO 14443A
ISO 14443B (Depending on specific
implementation)
ISO 15693 (including some partially
compliant credentials)
Other Standards
Compliance:
Deister SmartFrame® in both 125 kHz and
13.56 MHz implementations
HID® Prox at 125 kHz (All Formats)
PIN Code Entry Keys
(Model SWH-4200 only)
Twelve PIN code entry keys 0-9,
Command/Enter, and CE (Clear Entry)
Standard Color: Black (other colors available; contact your
Software House representative)
Dimensions with backplate
(height/width/depth):
4.37" × 3.31" × 1.10"
(110.99 × 84.07 × 27.94 mm)
Power Supply Rated Voltage: 9.4 to 16 VDC 125 mA
maximum current
Environments: For both Indoor and Outdoor Use
Humidity: 5 to 90% (non-condensing)
