BLUE - UNLOCK
GREEN - LOCK
NEGATIVE ONE WIRE RESISTANCE TYPE DOOR LOCKS
LOCK/UNLOCK SWITCH
87
87A
85
30
86
87
87A
85
30
86
GROUND (-)
GROUND (-)
12 VOLTS (+)
12 VOLTS (+)
UNLOCK RESISTANCE
LOCK RESISTANCE
BLUE - UNLOCK
GREEN - LOCK
POSITIVE ONE WIRE RESISTANCE TYPE DOOR LOCKS
LOCK/UNLOCK SWITCH
87
87A
85
30
86
87
87A
85
30
86
12 VOLTS (+)
12 VOLTS (+)
UNLOCK RESISTANCE
LOCK RESISTANCE
DOOR LOCK RELAY DIAGRAMS
