Configuration with Inverters with SetApp
Required inverter Firmware CPUversion : v4.7xx and later.
To associate the Smart Energy device with the inverter using SetApp:
1. Access SetApp as described in the
Inverter Installation Guide
.
2. Select Commissioning > Communication > ZigBee > Protocol > Home Automation.
3. Return to the Commissioning screen.
4. Select Device Manager. The Smart Energy Manager screen is displayed.
5.
Select Add Devices to start device association with the inverter. A 3 minute
countdown starts.
6.
Within the 3-minute time, depending on your device type:
Move the ON/OFF/P switch to P position and hold for more than 5 seconds.
Press the association button for 2 seconds.
SetApp indicates that the device has been associated.
7.
After all required devices have been associated, tap Stop in the Smart Energy
Manager to exit.
To configure the Smart Energy device:
1. Go to the monitoring platform web-site on your computer, or open the monitoring
platform application on your mobile device.
2. Click/tap the Smart Energy icon.
3. Select a device and go to Details and Settings.
4.
Complete the following information:
Rated power
Min active time
Device icon
Device name
5.
Return to the device screen and configure:
Schedules
Ready-by timers
Excess Solar Power mode (requires a SolarEdge Energy Meter)
Device state
Configuration 23
Smart Energy Hot Water Installation Guide MAN-01-00570-1.4
