SolarEdge Smart Energy Hot Water

STANDARD COMPLIANCE
Safety
UL 60730; CSA C22.2
Emissions
FCC part 15 class B
Radio
ETSI EN 300 328 V 1.8.1; ETSI EN 301
489-1; ETSI EN 301 489-17
INSTALLATION SPECIFICATIONS
Dimensions (H x W x D) 375 x 240 x 110 / 14.7 x 9.5 x 4.5 mm/ in
Weight 5.3 / 11.7 kg/ lb
Operating Temperature Range -10 to +50 / 14 to 122 °C / °F
Conduits
Support of ½ and ¾ inch conduits
(8-gauge wire)
Pre-drilled opening of 1.109 in.
Terminal Block Minimum Wire
Cross Section
15 / 1.5 AWG/mm
2
Maximum distance between
Device and Load/ Cable cross
section - for load size 3.0kW
3/10for 13 AWG/2.5 mm
2
20/65for 11 AWG/ 4 mm
2
m/ft
Protection Rating
NEMA3R
Mounting Type Wall mount
Mechanical specifications (mm):
Smart Energy Hot Water Specifications MAN-01-00571-1.1
2 Smart Energy Hot Water Specifications (North America)
