SolarEdge Smart Energy Hot Water

Indoor Range
(1)
50 / 164 m/ ft.
STANDARD COMPLIANCE
Safety
IEC-60730 -1
Emissions
EN61000-6-1,2,3; EN61000-4-
2,3,4,5,6,8,11
Radio
ETSI EN 300 328 V 1.8.1; ETSI EN 301
489-1; ETSI EN 301 489-17
INSTALLATION SPECIFICATIONS
Dimensions (H x W x D) 375 x 240 x 110 / 14.7 x 9.5 x 4.5 mm/ in
Weight 5.3 / 11.7 kg/ lb
Operating Temperature Range -10 to +50 / 14 to 122 °C / °F
Conduits
Pre-drilled openings of 25 mm for 2
conduits.
Terminal Block Minimum Wire
Cross Section
15 / 1.5 AWG/mm
2
Maximum distance between
Device and Load/ Cable cross
section - for load size 3.0kW
3/10for 13 AWG/2.5 mm
2
20/65for 11 AWG/ 4 mm
2
m/ft
Protection Rating
IP65
Pollution Degree 3
Mounting Type Wall mount
Mechanical specifications (mm):
(1)
Approximate values. May differ depending on specific installation conditions.
Smart Energy Hot Water Specifications MAN-01-00573-1.1
2 Smart Energy Hot Water Specifications (Australia)
