SolarEdge StorEdge BI-NUSGN-01 User Manual

Appendix D: StorEdge Backup Interface
Technical Specifications
PN
BI-NUSGN-01

AC FROM GRID   Unit
AC current input 200 A
AC output voltage (nominal) 240 Vac
AC output voltage range 211–264 Vac
AC frequency (nominal) 60 Hz
AC frequency range 59.3–60.5 Hz
Microgrid interconnection device 200 A
Grid disconnection switchover time <100 ms
AC TO MAIN DISTRIBUTION PANEL   
Maximum AC current output 200 A
AC L-L output voltage (nominal) 240 Vac
AC L-L output voltage range 211–264 Vac
AC Frequency (nominal) 60 Hz
AC Frequency range 59.3–60.5 Hz
Maximal inverters AC current output in
backup operation
78 A
Imbalance compensation in backup operation 5000 W
AC L-N output voltage in Backup (nominal) 120 V
AC L-N output voltage range in backup 105–132 V
AC frequency range in backup 55–65 Hz
INVERTER INPUT   
Number of inverter inputs 3 #
Rated AC power 7,600 W
Maximum continuous output current 32 A
Rated AC power in backup operation 6,100 W
Maximum continuous output current in
backup operation
26 A
Peak AC Power (<10 sec) in backup operation 7,000 W
Peak AC Current (<10sec) in backup operation 30 A
Inverter input AC CB 40 A
Upgradability
Up to 3 X 40A CB
(1)

(1)
Each 40A CB supports an 7600W inverter; CB upgrade kit is available with the following part numbers: for
40A CB CB-UPG-40-01
Backup Interface Installation Guide MAN-01-00728-1.0
26 Appendix D: StorEdge Backup Interface Technical Specifications

SolarEdge StorEdge BI-NUSGN-01 Specifications
