SolarEdge ZigBee User Manual

SolarEdge ZigBee Kit Quick Installation Guide
MAN-01-00155-1.0
8
LEDs
The gateway has four LED indicators, as follows:
Label and Color
Indication
Functionality
*
Link (yellow)
Communication with
associated slave(s)
Blinking - There has been
ZigBee communication in
the last 15 minutes. The
LED blinks according to the
number of slaves as follows:
for each slave 0.5 second
ON and 0.5 second OFF.
This is repeated following a
5 sec. pause.
OFF - No communication
with any slave in the last 15
minutes
S_OK (green)
Connection with the
SolarEdge
monitoring portal
ON - Connection with
SolarEdge monitoring portal
is OK
OFF - Communication with
the SolarEdge monitoring
portal failed
3x Signal
strength (green)
Received Signal
Strength Indication -
Low/Medium/High
All 3 LEDs ON - High
Two LEDs ON - Medium
One LED ON - Low
Power (green)
Power
Power supply connected to
the home gateway
*
Functionality during normal operation. During device discovery and diagnostic mode, the
LEDs indicate different functionality.
