Solax Maleta - Power Indicator; Direction Control Lever; Horn Button; Telescopic Tiller

6
3.4 Power Indicator (Fig.07)
When the scooter is turned to the “on” position, your battery
charge will show on the LCD display.
Fig. 07
3.5 Direction Control Lever
The direction control lever is used to control the forward and
backward.
Move the lever with your right hand to drive forward. (Fig.08)
Move the lever with your left hand to move backward. (Fig.09)
When the scooter moves backward, you will hear a beeping noise
The control lever will return to the center position when
released and the brake will engage. Causing the scooter to stop.
Please note: The direction levers can be “reversed” if required.
Fig.08
3.6 Horn Button - Fig.10
When you press the button, it will sound the horn.
Fig.09
Fig.10
3.7 Telescopic Tiller
Lift the latch, which will allow you to lift or
collapse the tiller. Once you have adjusted it
to your preferred height, push the latch down
to lock in the position. (Fig.11 & Fig.12).
Fig.11 Fig.12
