SOLE LCB - Page 6

LCB FITNESS BIKE 4

LCB ASSEMBLYPACKCHECKLIST

1
HARDWARE STEP1






#50. 3/8” x 2-1/4”
Hex Head Bolt (2 pcs)

2 
HARDWARE STEP2
#58. M5 x 12mm
Phillips Head Screw (2 pcs)
#71. 3/8” x 25mm x 2T
Flat Washer (2 pcs)




#51. 5/16” x 5/8”
Hex Head Bolt (7 pcs)

3
HARDWARE STEP3

#72.5/16”x18mmx1.5T
FlatWasher(6pcs)
#99. 5/16” x 19 x 1.5T
Curved Washer (1 pc)




#51. 5/16” x 5/8”
Hex Head Bolt (2 pcs)

4
HARDWARE STEP4
#72. 5/16” x 18mm x 1.5T
Flat Washer (2 pcs)
#103. 5/16” x 1.5T
Split Washer (2 pcs)

#58. M5 x 12mm
Phillips Head Screw (6 pcs)



