Solem LR-OL - Installation

16
INSTALLATION
Step 4
Several types of installaon are possible for your LR-OL.
Choose the example that you think is best for your situaon.
The LR-OL product has 4 relays (250V 16A), which can connect up to 3500 W
on a single line.
To avoid overheang and deterioraon of the device, it is not necessary to
exceed 4000 W distributed over the 4 relays.
The use of LED bulbs requires plugging in a power contactor (Schema No.3)
from a power of 150W LED bulbs.
1. A single line used with switch
You can parallel a back-and-forth switch with the programmer’s relay. Only
constraint, when the switch back and forth will be in the on posion no acon
will be possible with the programmer.
Bleu
Interrupteur
Rouge / Marron
Switch
Blue
Red/Brown
