Solid State Logic C100 HDS Specification

C100 HDS. This is SSL.
www.solidstatelogic.com
C100 HDS Specification
Hardware architecture:
- Frame sizes from 16+8 to 72+8 faders, with dual mains inlets and redundant PSUs
- Blackrock processor core with RAID 1 disk array, providing console control interface and self-healing audio
processing
- Option to upgrade to dual Blackrock processor cores, offering total redundancy for CPU, DSP, MADI I/O, SSD, and
file system
- 4 MADI I/O ports or a redundant Blacklight port offering up to 256 channel audio interfacing, with embedded
control data for all SSL I/O solutions
- Option to upgrade to 8 MADI I/O ports, 4 Madi Ports together with a Redundant Blacklight port, or two redundant
Blacklight ports offering up to 512 channel audio interfacing
- Integration Computer providing secured network login for file management, SNMP and remote diagnostics
- MORSE optical MADI routing option allows networked resource sharing and extensive IO capacity.
- Option to expand GPI/O via network controlled 24 or 48 channel 1U units
- Production automation interface option
DSP architecture:
- Up to 256 full input channels, each with dedicated 4-band EQ, Comp/Lim, Gate, Alt. Input, Insert and Direct Output
- Second input path provides up to 512 channels to mix.
- 24 mono Utility Busses for Mix Minus, IFB, recording and clean feeds - can be formatted as 5.1, stereo or mono
- 24 mono Aux busses with odd/even stereo bus linking
- 16 dedicated ASG buses, formatted as 8 x stereo or 2 x 5.1 & 2 x stereo, with inserts and comp/lim processing
- 12 dedicated PGM buses, formatted as 2 x stereo, 2 x 5.1, or 1 x 5.1 & 1 x stereo, with inserts, comp/lim, and LFE filters
- Dual independent channel outputs can provide ‘N-1 and direct recording feeds simultaneously
- 64 Delay modules, 5.4 seconds each, assignable to input channels, ASG buses and Program buses or as stand
alone delay channels to feed monitoring and comms circuits
- Independent stereo PFL and AFL monitoring
- 4 x 12 way external monitor source selectors (5.1/stereo)
- 16 mono direct inputs with level, on/off and AFL, can be linked for stereo/5.1 operation and can feed any and all
console buses
- 2 communications mixes, each with 2 x stereo source selection, level, on/off, AFL, T/B and on-air mute logic
- 3 monitor buses, in 5.1, stereo and stereo/mono formats, with insert point, source selection, solo/mute, phase
and level control
- In-built 5.1 BLITS tone generator routes to all 5.1 format PGM, ASG, Channel and Utility Buses
Max Height................................100.6cm (39.61”)
Height Adjustment.....................-0,+1cm (-0”,+0.39”)
Width 40 fader (flat end trim) .....143.1cm (56.34”)
Each bay adds/subtracts ...........28.5cm (11.22”)
Contoured end trim adds ...........7.2cm (2.83”)
Max Depth.................................92.6cm (36.46”)
Weight (40 fader).......................~190kg (~419lb)
Each bay adds weight ................~35kg (~77lb)
Console Power...........................100-240V AC,
(dependent on frame size) 300-700W
Control Surface Cooling Method .Convection (silent)
Physical and Environmental Specification
Solid State Logic
International HQ: Begbroke, Oxford, England OX5 1RU · Tel +44 (0)1865 842300 · sales@solidstatelogic.com
© Solid State Logic. All Rights reserved under International and Pan-American Copyright Conventions. Solid State Logic and SSL are trademarks of Solid State Logic. All other trademarks are the property of their respective owners.
No part of this publication may be reproduced in any form or by any means, whether mechanical or electronic, without the written permission of Solid State Logic, Oxford, England. Solid State Logic has a policy of continual product
enhancement and reserves the right to alter specifications without notice. E&OE
Cologne: Tel +49 7001 8658 42300 · sales@solidstatelogic.com
Italy: Tel +39 3355 870 703 · itsales@solidstatelogic.com
Los Angeles: Tel +1 213 249 9229 · lasales@solidstatelogic.com
New York: Tel +1 212 315 1111 · nysales@solidstatelogic.com
Paris: Tel +33 (0)1 48 67 84 85 · frsales@solidstatelogic.com
Singapore: Tel +65 6438 2272 · sales@solidstatelogic.com
Thailand: Tel +66 2 587 5111 · akaraphol@ssl-bkk.com
Tokyo: Tel +81 (0)3 5474 1144 · jpsales@solid-state-logic.co.jp
Zagreb: Tel +38 513 079 405 · sales@solidstatelogic.com

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
