Solid State Logic C100 HDS Specification

C100 HDS. This is SSL.
www.solidstatelogic.com
Custom conguration, seamless integration, exemplary
support, total reliability and ultimate peace of mind…
The C Control Surface, Processing and I/O are modular and scalable. Through consultation we ensure each system is specied and built to exactly match your current
requirements whilst retaining the facility for future expansion. We then provide rst class installation, conguration and training, to make sure your system and sta are ready on
time to deliver pristine HD ready audio.
The C oers the exceptional level of reliability broadcasters require. All of the C’s console computer systems are % proprietary, so our system is extremely stable,
rewalled and % virus-proof. The C features internal self-testing, error-correcting soware so conditions which might result in a fault are quickly detected and resolved
before they cause problems. The C provides extensive SNMP remote diagnostics soware, allowing remote, automated console interrogation, signicantly streamlining
maintenance operations. The C system takes redundancy to the next level with capability to run two completely mirrored system set ups each with their own processing and
I/O hardware, with a single control surface. Maintenance of a fully mirrored system means that in the unlikely event of a failure, switch over from the main to backup system is
almost instant with current project settings intact.
Blackrock Processor
The Blackrock processor provides the
speed, stability and flexibility expected
of purpose-built SSL processing,
customised to your requirements. You
specify the required console channel
count, and we will scale the Blackrock to ensure that dedicated processing is
available for every channel. Future expansion is by soware license. Blackrock is a
U chassis with Ethernet console network connection and audio I/O via standard
MADI and SSL’s proprietary Blacklight audio I/O which delivers  channels using a
single standard bre optic cable.
I/O Options
Alpha-Link LIVE-R & 8RMP
Cost-eective multi-use I/O
Alpha-Link LIVE-R is a stand-alone audio
converter that can be specied as low
cost console I/O. It provides bi-directional
conversion between ch MADI bre I/O,
ch line level analogue and ch AES digital I/O simultaneously. The Alpha-Link
RMP is an ch mic pre to ch analogue line converter. Up to three RMP units
connect to an Alpha-Link Live and can be remotely controlled by the C via the
Alpha-Link Live MADI bre cabling.
B-RIO - High density local I/O
B-RIO provides up to  channels of
advanced, modular local console I/O,
customised to meet your requirements.
B-RIO connects to the console using either
standard MADI bre or SSL’s proprietary
Blacklight system which delivers 
channels using a single standard bre optic
cable. Control data and SNMP diagnostics
are embedded in the cabling. B-RIO oers 
card slots which can house a combination of Mic/Line, Line and AES digital cards.
MORSE I/O Sharing Application Example
MORSE Router
For multi-studio broadcast facilities the
MORSE Router provides a flexible solution for
sharing audio I/O between multiple studios
and control rooms and managing related control data. The MORSE resource sharing
system is congured from a standalone computer but allows seamless reallocation of
projects and signal feeds without any re-plugging, controlled from the console surface.
The MORSE Router can be used with both C and C consoles.
Additional I/O Options
• SDI-MADI: A G SDI audio de-embedder providing four auto sensing SDI Inputs to
MADI and AES Digital Audio Outputs.
• MADI-Dante Bridge: Fully redundant U unit that provides a  ch @ kHz
interface between any MADI device and a Dante IP Audio network.
• Remote GPIO: A U unit which can provide up to  channels of GP input and output
connected to the console network via Ethernet.
MORSE Stagebox - Modular
versatile I/O stagebox
MORSE Stageboxes provide an I/O
solution wherever you need it. Each
Stagebox oers  channels of modular I/O connected to the console via MADI bre
with control data embedded in the cabling. Each MORSE Stagebox oers  card slots
which can house a combination of Mic/Line, Line, AES digital and SDI (HD or SD)
Embedder/De-embedder cards.
Routing and Resource Sharing

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
