LPMU SPECIFICATION
The LPMU amplifies downlink RF signal and then filters the signal, and for uplink, it filters and amplifies
uplink signals in sequential order. The following table shows LPMU specification.
The following table shows the LPMU specification.
LRFU Types
Uplink
Downlink
Range
BW
Range
BW
LPMU_700_8085_1900_2100_2300_2500
699 – 716
17
729 – 768
39
776 – 798
21
817 – 849
32
862 – 894
32
1850 – 1915
65
1930 – 1995
65
1710 – 1780
70
2110 – 2180
70
2305 – 2315
10
2350 – 2360
10
2497.4 – 2687.4
190
2497.4 – 2687.4
190
Item
Specification
Remark
DL Output Power
+20dBm composite power per band
UL Input Power
Max. -40dBm w/o ALC function
Max. -38dBm w ALC function
Nominal Impedance
50ohm
VSWR
1.8:1
Type of External Antenna Port
SMA_F
System Ripple
±2dB
UL ALC Control Range/step
0 ~ 20dB/0.1dB
