Booster
Inside Antenna
Package Contents
Working Diagram (How It Works)
The size and the coverage area and the strength of the boosted signal are directly related
to two key factors:
1. Signal strength received by the outside antenna.
2. Distance of separation between the outside antenna and the inside antenna.
1. The outside antenna catches the signal from the tower, transmit it through a coax
cable into the booster.
2. Booster amplifies the signal and then transmit it through a coax cable to the inside
antenna.
3. The inside antenna rebroadcasts the signal inside to all mobile devices within range.
4. The system also works in reverse; amplifying outgoing signal back to the tower.
The kit includes the following items:
1. Booster；
2. Inside Antenna;
3. Power supply;
4. Outside Antenna;
Power adaptor
Outside Antenna
2
1
2
3
