SolidRF Signal Plus - Signal Level Knowledge; Signal Transmission Loss and Power Levels; Coverage Area Ability Explained

Signal transmission loss and power level
Coverage area ability
3
Note: FCC regulations limit the amplification of all cell phone boosters in order to
prevent damage to the telecommunications infrastructure. Therefore, the maximum
coverage area of a booster depends on the original power level of the signal captured by
the outdoor unit.
Notice: Not recommended when outdoor signal strength is less than -110dbm(3G/1x)
or -120dBm(4G/LTE). The resulting coverage area of the boosted signal will be
prohibitively small.
Power level
at the outdoor antenna location
Coverage Area @ One Antenna
(sq. ft.)
Coverage Area @ Two Antenna
(sq. ft.)
Strong (5 bars on the cellphone)
5,000
8,000
Medium (3~4 bars on the cellphone)
2,500
4,000
Weak (1~2 bars on the cellphone)
600
1,000
