SolidRF SR14652002A - Working Diagram; Package Contents




WorkingDiagram(HowItWorks)
PackageContents
1. Theoutdoorantennacatchesthesignalfromthetower.
2. Sendsoutsidesignaltotheboosterthroughacoaxcable.
3. Theboosteramplifiesthesignalthenrebroadcaststhesignalindoorstoallmobile
deviceswithinrange.
4. Thesystemalsoworksinreverse;amplifyingoutgoingsignalbacktothetower.
Thekitincludesthefollowingitems:
1. OutdoorAntenna(withmountingkits);
2. Booster(withindoorantenna);
3. Powersupply;
4. 60ftofRG6cable,forconnectingtheoutdoorunitandindoorunit;
Thecoverageareaandthestrengthoftheboostedsignalaredirectly
relatedtotwokeyfactors:
1. Signalstrengthreceivedbytheoutdoorunit.So,settinguptheoutside
unitwherethesignalisthestrongestwillprovidethebestresults.
2. Distanceofseparationbetweentheoutdoorunitandtheindoorunit.
2
OutdoorAntenna
Booster&IndoorAntenna
Powersupply
RG6cable
