Your SOLO chainsaw - Components and functional parts under the cowl
ENGLISH 15
E
N
G
Settings for winter operation / standard operation
To prevent the carburettor icing-up at low outside temperatures (below 5 °C), the inlet air can be
preheated by adjusting the slide insert (33) for winter operation.
A) Winter operation.:
Turn the slide insert so that the winter
symbol is visible and the aperture
points downwards.
B) Standard operation:
At ambient temperatures from 5 °C, always
close the connection to the cylinder
chamber with the slide insert (opening the
slide insert and with the sun symbol visible).
Failure to do so can lead to engine damage
as a result of overheating.
To safeguard that the slide insert securely locks into place, the winter symbol must always be
visible in the winter position (aperture pointing downwards); during standard operation (aperture
pointing upwards ! connection to the cylinder chamber closed), the sun symbol must be
visible. During the installation, the slide insert must securely click into place.
Removal and replacement of the air filter
a) Always pull out the choke lever (7) before removing the
air filter (32) to prevent any dirt from getting into the intake
opening of the carburettor.
b) Unlock the spring clamp by pressing down on its centre part.
c) Remove the air filter upwards.
d) During the installation, hold the spring clamp open by pressing
down on its centre part (d*).
e) After the air filter has been installed, lock it in place by
pressing down on the sides (e) of the spring clamp, until it locks
into place.
• The standard fleece filter is designed for dry and dusty
working conditions.
• The additionally supplied nylon filter is designed for damp
working conditions.
