Your SOLO chainsaw - Specification
ENGLISH 19
E
N
G
3.10 Specification
Chain saw 665 / 665H 675 / 675H 681 / 681H
Engine type SOLO single cylinder two-stroke engine
Engine capacity cm
3
65,9 74,6 80,7
Bore / stroke mm 47 / 38 50 / 38 52 / 38
Max. power at rpm kW / rpm 3,6 / 9.500 4,3 / 9.500 4,7 / 9.500
Max. torque at rpm Nm / rpm 4,3 / 6.000 4,8 / 6.500 5,3 / 6.500
Max. permissible speed rpm
no load with cutter
13.500 13.500 13.500
Medium idling speed rpm 2.600± 200
Fuel tank capacity l 0,75
Fuel mix ratio:
with SOLO 2T engine oil
with other two-stroke oils
1 : 50
1 : 25
Capacity of the chain lubrication oil tank l 0,42
Carburettor All-position diaphragm carburettor with
primer and integrated fuel pump
Air filter Fleece filter for dry working conditions
Nylon filter for damp working conditions
Ignition Electronically controlled magneto ignition,
maintenance free
Sprocket / teeth Ring sprocket / 7
Dimensions Height mm
Width mm
Length mm
for version with a cut length of cm (’’)
315
255
850
40 (16)
315
255
900
45 (18)
315
255
950
50 (20)
Weight without tank contents, guide bar and chain kg 6,7 6,65 6,6
In determining the following values regarding the acceleration of vibrations and sound, the different
operating conditions were weighted in accordance with the current standards
Sound pressure level L
Peq
(EN ISO 22868) dB(A) 102 102 104
Sound power level L
Weq
(EN ISO 22868) dB(A) 111.4 111,7 113,5
Weighted effective acceleration a
hv,eq
(DIN ISO 22867)
Handle r.h. side / handle l.h. side m/s
2
5,01 / 4,37 5,85 / 4,75 5,33 / 5,40
Build year of the power tool ! refer to the type plate on the power tool (Chapter 3.3, "Symbols on the
equipment and on the type plate").
Permissible cutting gear and the corresponding cutting lengths – see Chapter 9, "Permissible cutting
gear and further accessories" (page 40)
