Technical Specifications
Below outlines the technical specifications for your Washing Machine.
Model GGSFLW600 GGSFLW700
Washing Capacity 6.0kg 7.0kg
Dimensions (W × D × H mm) 595 × 400 × 850 mm 595 × 565 × 850 mm
Net Weight 55kg 68kg
Rated Power 2000W 2000W
Power Supply 220-240V, ~50Hz, 10Amp 220-240V, ~50Hz, 10Amp
Standard Water Pressure 0.05MPa~1.0MPa 0.05MPa~1.0MPa
TESTING METHODS:
GGSFLW600
ADDITIONAL INFORMATION FOR STANDARD PERFORMANCE TESTING:
(AS/NZS 2040.1:2005+Amdt1-2007+Amdt2-2009)
1. Water connections: Cold & hot water connection
2. Water supply pressure: 320 kPa
3. Warm wash Program: ECO Wash, 60°C, Spin 1200 RPM, Display: 4:50
Cold wash program: Cotton Cold (no temperature display is cold wash)
4. Detergent type: Drum detergent
5. Detergent quantity: Default
6. Adding detergent:
The detergent is dissolved and added as Paragraph B7.3 of AS/NZS 2040.1
The detergent shall be dissolved in 1 L of water
7. Anti-sudsing agent: Max
8. Test load mass: 6.0kg
9. Water consumption: 61L
10. Test Voltage: 220-240V~,50Hz
GGSFLW700
ADDITIONAL INFORMATION FOR STANDARD PERFORMANCE TESTING:
(AS/NZS 2040.1:2005+Amdt1-2007+Amdt2-2009)
1. Water connections: Cold & hot water connection
2. Water supply pressure: 320 kPa
3. Warm wash Program: ECO Wash, 60°C, Spin 1400 RPM, Display: 5:34
Cold wash program: Cotton Cold (no temperature display is cold wash)
4. Detergent type: Drum detergent
5. Detergent quantity: Default
6. Adding detergent:
The detergent is dissolved and added as Paragraph B7.3 of AS/NZS 2040.1
The detergent shall be dissolved in 1 L of water
7. Anti-sudsing agent: Max
8. Test load mass: 7.0kg
9. Water consumption: 72L
10. Test Voltage: 220-240V~,50Hz
