Preparations for assembly
Safety instructions
ATTENTION!
Follow all installation directions. Improper installation may
cause serious injuries.
• The voltage of the power source must correspond with the voltage
listed on the operator type plate.
• The contacts of all devices to be connected externally must be safely
isolated from the mains voltage supply according to IEC 60364-4-41.
• Comply with the standard IEC 60364-4-41 when laying the leads of
the external devices.
• The operator may be installed, connected and commissioned by
competent personnel only.
• Do not move the gate, if there are any people, animals or objects in
the area of movement.
• Keep children, disabled persons and animals away from the gate.
• Wear safety glasses when drilling the fastening holes.
• Cover the operator during drilling to prevent dirt from entering the
operator unit.
ATTENTION!
The foundation must be solid and stable. Only install the
operator on a correctly aligned gate. An incorrectly aligned
gate could cause serious injury.
• Gates must be stable in themselves, since high traction and
compression forces are encountered. Reinforce lighter gates made of
plastic or aluminium if necessary before installation. Ask a specialist
retailer for advice.
• Remove or disable gate locks.
• Use only approved fasteners (e.g. anchor fittings, bolts). The fasteners
must match the material of the ground.
• Check the gate for smooth operation.
Tools required
5 mm 10 mm
10 mm
13 mm
8 mm
Personal protective equipment
• Safety glasses (for drilling).
• Work gloves.
Scope of supply
• Check the package before installation to avoid unnecessary work and
expense if a part is missing.
• The actual scope of supply may vary depending on the operator version.
Bedienungsa
nleitung
1
D
D
6
3
2
4x
24x
24x
1
5
4
8
7
Complete set
Package (l x w x h) 1035 × 350 × 270 mm
Weight 12 kg
1. 1 pc. Sliding gate operator with controller and radio receiver
2. 1 pc. Console
3. 1 pc. Installation and Operating Manual
4. 1 pc. 4-command handheld transmitter
5. 4 pcs. 1 m rack
6. 2 pcs. Limit switch
7. 1 pc. Auxiliary mounting plate x 4 pcs.
Spring washer x 2 pcs.
Screw x 2 pcs.
U-washer x 2 pcs.
Lock washer x 2 pcs.
Key x 2 pcs.
8. 1 pc. Installation bag (fasteners)
Screw x 24 pcs.
24 pcs. Washer
Single operator
Package (l x w x h) 400 × 355 × 225 mm
Weight 8 kg
1. 1 pc. Sliding gate operator with controller and radio receiver
2. 1 pc. Console
3. 1 pc. Installation and Operating Manual
4. 2 pcs. Key for cover
8. 2 pcs. Solenoid limit switch
