SonicWallNSA2600/3600/4600/5600/6600GettingStartedGuide
27
InternetAccess
SonicWall Appliance
120V AC
(U.S.)
SonicWall NSA 5600
CONSOLE
SDHC
MGMT
X17
X16
X14 X12 X10 X8 X6 X4
1GE
10GE
X2 X0
X1X3X5X7
X9X11X13X15
ALARM
M0
TEST
PWR
X0 (LAN)
X1 (WAN)
Internet
Ethernet
X
X1
X
X0
X1
