SonicWallSonicPointACeGettingStartedGuide
17
MountingtheSonicPointACe
YoucanmountyourSonicWallSonicPointACetoawallor
ceiling,oryoucansimplysetitonaflatsurface.
Forsafetytipswhenmounting theSon icPointACe,seeProduct
safetyandregulatoryinformationonpage29.
Mountingusingceilingbrackets
Themountingkitincludesalargebracket,twosmallbrackets,
anchorscrews,andscrews.
Largeceilingbracket
Smallceilingbrackets
TheundersideoftheSonicPointACehastwoinsertionpoints
forthescrews.Youcanusetheseinsertionpointstoattach
eitherthelargebracketorthetwosmallbracketstothe

SonicPointACe.
Holesforscrews
