SonicWALL SonicPoint ACe - Page 19

SonicWallSonicPointACeGettingStartedGuide
19
TomounttheSonicPointACetoacrossbarbetween
ceilingpanelsusingthesmallceilingbrackets:
1Usetheincludedscrewstoattachthesmallbracketsto
theundersideoftheSonicPoint,makingsureboth
bracketsareparallel.
2 SupportingtheSonicPointinonehand,cliptheedgeof
eachbracketovertheedgeoftheceilingcrossbaras
showninthefollowingimage.MakesuretheSonicPoint
is
securelyattachedtothecrossbarbeforereleasingthe
device.
Ceiling crossbar
Mounting brackets
SonicPoint unit
