Sonim XP3340 SENTINEL User Manual

69
Micro SD Card
Micro SD (Secure Digital) Card
In Sonim XP3340 SENTINEL phone, you can insert
a removable Micro SD Card to increase the storage
capacity. This card is inserted into the slot inside the
phone. You can perform the following functions on the
SD card.
•  Formatting of the SD card.
•  Viewing memory details such as free space and total
space.
•  Setting the images in the SD card as wallpaper.
•  Setting the audio les in the SD card as ringtones.
The maximum capacity supported is up to
16 GB.
Inserting Micro SD Card into the Phone
1 . Ensure the phone is switched off.
2 . Lift the battery cover and remove the battery. For
instructions refer “Inserting the Battery” on page 14.
3 . Slide and lift the silver clip over the designated slot
located below the SIM card slot.
4 . Place the SD card in the designated slot and close
the silver clip.
5 . Replace the battery and the cover. Turn the battery
cover screws clockwise to lock the battery cover.
When the Sonim XP3340 SENTINEL phone is
connected to a computer using USB, the Micro
SD card is displayed as a separate drive in the
computer.

Sonim XP3340 SENTINEL Specifications

Operating Environment

operational temperature range	-20˚C to +55˚C
vibration protection	5Hz to 500Hz
shock resistance	up to 4G

Display

display size	2 inch
display resolution	240x320
display brightness	280cd/m²

Battery

battery capacity	1750 mAh
talk time	20 to 24 hours
standby time	over 800 hours

Camera

camera resolution	2 MP
camera features	LED Flash
torch light	LED

Ports & Interfaces

headset port	3.5mm waterproof
USB data port	proprietary cable
Bluetooth version	2.1

Weight and Dimensions

size	126mm x 60mm x 25mm
weight	185 grams
impact resistance	2 meter drop onto concrete
