15Instruction for use | Superaqua 1
8. Standard radio settings
Term OMS settings
Encryption Mode 5
AES128 key Individual
wM-Bus OMS short telegram
wM-Bus transmission mode T1
Radio calendar Mo-Su, 0.00 to 23.59, Jan-Dec.
Transmission interval 2 Min.
End of device life reached (D/Ö) No
Display ow rate Yes
Leackage Yes
8.1 Radio settings conguration
To congure the radio settings you can use the parameterization software Superprog. You will
nd instructions for setting the radio parameters in the help menu of the Superprog software.
8.2 Radio connections

Sontex Radio
Frequency: 433 MHz, bidirectional, transmission power: 10 dBm (10 mW)

wM-Bus OMS
Frequency: 868 MHz, unidirectional, Mode 5 or 7, Radio telegram C1 or T1, transmission power: 14 dBm (25 mW)

LoRaWAN
Frequency: 868 MHz, bidirectional, transmission power: 14 dBm (25 mW)
9. Technical data
Dimension

Single Jet
lenght L
height H

Multi-Jets measuring capsule
Diameter D1
Diameter D2
height H
80, 110, 115, 130, or 165 mm
approx. 52 mm
75 mm
70 mm
from 35 to 62 mm
Measurement

Approved temperature Cold water

Approved temperature Warm water

Volume measurement cycle at nominal ow
+0.1°C ... +50°C
+0.1°C ... +90°C
0.5 seconds
Digital Register

Environment class

Mechanics

Electronics

Battery protection class

Protection class

Operating temperature

Storage and transport temperature
B
M1
E1
III
IP68 (4 weeks under 1m water)
5...55°C
-10...60°C (dry environment)
Display & Display Units

LCD

Volume resolution (display)

Volume
 Flow
 Flow symbol (flashes when there is flow)

Battery status
 Radio
8 digits
0.001
m
3
l/h
Power Supply

Lithium Battery (< 1 g) 3 VDC up to 15 years
