Sontex Supercom 636 - Annex B: Device List for Reading; 7.1 Add Entry to Device List for Reading

Manual Supercom 636 R+W rev. 010312 15
7. Annex B
7.1 Add entry to device list to read a device
Identification Number
Manufacturer ID Generation of Meter Measured Media Radio Address Radio Device Type Options
Maximal Frame Number
Application Reset Subcode
Date of Last Successful Reading
Type A C C D A C D C D G
Bytes 4 2 1 1 4 1 1 1 1 2
Notes a, e a, e a a b, e b b b b c, e
Device type Values to read
HCA 502, 502S, 552
All values xxxxxxxxh 4DEEh 4 08h xxxxxxxxh 0 80h 01h 00h 0101h
HCA 502S, 552
All values (compact reading) xxxxxxxxh 4DEEh 4 08h xxxxxxxxh 0 80h 01h 01h 0101h
Supercal 539 or 539+
Current values xxxxxxxxh 4DEEh 4 04h xxxxxxxxh 1 80h 01h 00h 0101h
Supercal 539+
+ monthly energy xxxxxxxxh 4DEEh 4 04h xxxxxxxxh 1 80h 02h 00h 0101h
Supercal 539+
+ monthly volume xxxxxxxxh 4DEEh 4 04h xxxxxxxxh 1 80h 03h 00h 0101h
Supercal 539+
All values xxxxxxxxh 4DEEh 4 04h xxxxxxxxh 1 80h 05h 00h 0101h
540 pulses
All values xxxxxxxxh 4DEEh 1 00h xxxxxxxxh 2 80h 04h 00h 0101h
531 / 449
frames 1, 2, 3, 4 xxxxxxxxh 4DEEh 12 04h xxxxxxxxh 3 80h 04h 00h 0101h
531 / 449
frames 1, 2, 3, 4, 5, 10 xxxxxxxxh 4DEEh 12 04h xxxxxxxxh 3 80h 06h 01h 0101h
531 / 449
frames 106, 107 xxxxxxxxh 4DEEh 12 04h xxxxxxxxh 3 80h 04h 02h 0101h
531 / 449
frames 56, 57, 58, 59 xxxxxxxxh 4DEEh 12 04h xxxxxxxxh 3 80h 04h 03h 0101h
590 WCA
All values xxxxxxxxh 38AFh 4 07h xxxxxxxxh 4 81h 01h 00h 0101h
580 Water counter
All values xxxxxxxxh 4DEEh 10 07h xxxxxxxxh 4 80h 01h 00h 0101h
581 Water counter
All values xxxxxxxxh 4DEEh 20 07h xxxxxxxxh 4 80h 01h 00h 0101h
556 HCA
All values xxxxxxxxh 4DEEh 16 08h xxxxxxxxh 5 B1h 02h 00h 0101h
541 pulses
All values xxxxxxxxh 4DEEh 10 00h xxxxxxxxh 6 90h 03h 00h 0101h
656 repeater All values xxxxxxxxh 4DEEh 30 0Eh xxxxxxxxh 6 00h 01h 00h 0101h
Notes
a This value is part of the M-Bus secondary address used to access the data of a device stored in 636.
It is updated by 636 according to the value really read from the device by radio.
b This value is used to access the device by radio. It is never modified by the 636 itself.
c
The date 1.1.2000 means ""not yet successful read"", coded in M-Bus G type: 0101h
e Multibytes values are transmitted with LSB first.
Options
bit7 Adjust device clock: 0=no, 1=yes
