Manual Supercom 636 R+W rev. 010312 17
Rsp_2
Field
Frame bytes in hex (Note 1) Coding Comment
Star t, Length
68,Le Le,68
Control
08
Respond w ith user data, RSP_UD
Control Information
72
Variable structure respond
Identification number
xx xx xx xx
A, 32 bits
Manufacturer ID
EE 4D
C, 16 bits "SON"
Version of meter
01
C, 8 bits
Signature (not used)
00 00
C, 16 bits
Identification number
8C 40,79, xx xx xx xx
A, 32 bits
Medium string
8D 40,FD 09,03,me me me
LVAR
Units string
8D 40,FD 67,05,un un un un un
LVAR 3 char
Units factor
85 40,EE 76,xx xx xx xx
H, 32 bits 5 char
Totalizer initial value
C4 40,6E,xx xx xx xx
B, 32 bits dimensionless
8D 40,FD 0C,18,ch ch ch ch ch ch ch
ch ch ch ch ch ch ch ch ch ch ch ch
ch ch ch ch ch
Totalizer current value
84 40,6E,xx xx xx xx
B, 32 bits 24 char
Units stored at month - 1
84 41,6E,xx xx xx xx
B, 32 bits
Units stored at month - 2
C4 41,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 3
84 42,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 4
C4 42,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 5
84 43,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 6
C4 43,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 7
84 44,6E,xx xx xx xx
B, 32 bits
Units stored at month - 8
C4 44,6E,xx xx xx xx
B, 32 bits
Units stored at month - 9
84 45,6E,xx xx xx xx
B, 32 bits
Units stored at month - 10
C4 45,6E,xx xx xx xx
B, 32 bits
Units stored at month - 11
84 46,6E,xx xx xx xx
B, 32 bits
Units stored at month - 12
C4 46,6E,xx xx xx xx
B, 32 bits
Units stored at month - 13
84 47,6E,xx xx xx xx
B, 32 bits
Units stored at month - 14
C4 47,6E,xx xx xx xx
B, 32 bits
Units stored at month - 15
84 48,6E,xx xx xx xx
B, 32 bits
Units stored at month - 16
C4 48,6E,xx xx xx xx
B, 32 bits
More records in next telegram
mo
Start of manufacturer specific data
