Rsp_4
Field
Frame bytes in hex (Note 1) Coding Comment
Start, Length
68,Le Le,68
Control
08
Respond with user data, RSP_UD
Address
xx
Control Information
72
Variable structure respond
Identification number
xx xx xx xx
A, 32 bits
Manufacturer ID
EE 4D
C, 16 bits "SON"
Version of meter
01
C, 8 bits
Device type
00
D, 8 bits
Access number
xx
C, 8 bits
Status
st
Ds, 8 bits
Signature (not used)
00 00
C, 16 bits
Identification number
8C C0 40,79, xx xx xx xx
A, 32 bits
Medium string
8D C0 40,FD 09,03,me me me
LVAR
Units string
8D C0 40,FD 67,05,un un un un un
LVAR 3 char
Units factor
85 C0 40,EE 76,xx xx xx xx
H, 32 bits 5 char
Totalizer initial value
C4 C0 40,6E,xx xx xx xx
B, 32 bits dimensionless
Info string
8D C0 40,FD 0C,18,ch ch ch ch ch ch
ch ch ch ch ch ch ch ch ch ch ch ch
ch ch ch ch ch ch
LVAR dimensionless
Totalizer current value
84 C0 40,6E,xx xx xx xx
B, 32 bits 24 char
Units stored at month - 1
84 C1 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 2
C4 C1 40,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 3
84 C2 40,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 4
C4 C2 40,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 5
84 C3 40,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 6
C4 C3 40,6E,xx xx xx xx
B, 32 bits dimensionless
Units stored at month - 7
84 C4 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 8
C4 C4 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 9
84 C5 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 10
C4 C5 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 11
84 C6 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 12
C4 C6 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 13
84 C7 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 14
C4 C7 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 15
84 C8 40,6E,xx xx xx xx
B, 32 bits
Units stored at month - 16
C4 C8 40,6E,xx xx xx xx
B, 32 bits
More records in next telegram
mo
Start of manufacturer specific data
Check Sum
cs
Stop
16
