Manual Supercom 636 R+W rev. 010312 29
Param556 in FRAME PARAMETRIZE
68 L L 68
4B FE B0
02 2C 00 26 5A 6F 12 00 02 5D 20 44 02 54 70 79
05 00 5C 09 35 6C 58 47 3E 18 66 6C 5E 09 16 69
66 6C 54 18 BB 63 B8 47 1E 73 74 46 0E 6F 12 00
06 FC 01 6D F0 5D 20 6D 70 40 14 6C 52 6C 5A 68
63 14 23 16 A3 68 E3 0C 4A EA 7F 18 22 09 26 0A
0B AB 08 45 D0 40 BE 7F 77 72 30 FA 04 54 70 5A
FB
PARAM
00
CS 16
PARAM: (one or more, order insignificant)
ID number
01 12 04 xx xx xx xx BCD M-Bus format A
KC and KQ factor
[3]
float M-Bus format H
02 0E 81 20 FF 03 14 04 xx xx xx xx xx xx xx xx
Date and time
01 0C 04 xx xx xx xx
Set day 02 0E 81 02 FF 02 16 02 xx xx M-Bus format G
(year will be '00)
Two different periods
Summer period start
date, Winter period
start date
0C 16 02 xx xx xx xx M-Bus format G (year will be '00)
Reset max. heatsink temp. 0C 20 02 00 00 00 00
[3]
Param556 is a frame wrapped in SND_UD
frame, it has also a similar header and
footer. The "L" (lenght) and "CS"(checksum)
bytes must be calculated.
L (length) and CS (checksum)
To disable this function, put the date 2000-01-01 into the 2 dates.
If KC or KQ = 0 then the device will count in "unit scale" mode.
Otherwise will count in "product scale" mode.
