Display time for an
item set as "long
time"
2..7s
2s 20 0E 81 40 5F
3s 20 0E 81 60 7F
4s 20 0E 81 80 9F
5s 20 0E 81 A0 BF
6s 20 0E 81 C0 DF
7s 20 0E 81 E0 FF
LCD Position_2,3,4,5,6,7,8 FE 1C 01 xx xx xx xx xx xx xx
00h = disable position (not allowed in POS2)
01h = errors position
02h = current date position
03h = set day position
04h = set day value position
05h = checkcode position
06h = ambient temperature position
07h = value at the end of the last period position
0Ah = temperatures menu
14h = values menu
1Eh = times and dates menu
22h = max. heatsink temperatures menu
2Bh = service menu
3Bh = metrological menu
92h = monthly menu
D2h = half monthly menu
finalizeParam556 in FRAME FINALIZE PARAMETRIZE (always necessary)
68 L L 68
4B FE B0
02 2B 00 32 AE 6F 10 00 0E 0B 00 68 04 F5 00 68
85 79 02 00 B0 09 32 68 2C AC 01 46 02 70 34 69
12 FD 3C 1D 52 47 38 45 12 70 44 68 84 6F 12 00
08 5D 20 40 72 09 62 69 A5 54 70 79 05 31 9C 0D
32 79 06 00 7E 55 EE 79 05 21 8A FE 0A 55 E6 79
05 21 A2 FE 14 55 DE 79 05 0F 8A FE 04 55 D6 73
74 47 24 6F 12 00 16 6F 23 FF F8 6F A3 00 0A 79
05 01 01 6F A5 00 08 1B 02 1B 82 6D F2 19 55 19
66 5E 00 31 DA 0B 87 73 14 47 04 5E 00 21 9C 73
34 47 0C 7F 76 70 20 7F 7B 70 10 7F 7B 72 20 5E
00 21 B4 5E 00 0F 58 FA 02 3A C1 7F FB 72 00 FA
04 54 70 8B 99
WS
CS 16
WS (byte)
= 1
Finalize write in 556 and put device in sleep mode
= 0 Finalize write in 556
POS8
We can not change the POS1 of LCD (Errors menu) and we must not disable POS2.
finalizeParam556 is a frame wrapped in
SND_UD frame, it has also a similar header and
footer. The "L" (lenght) and "CS"(checksum)
bytes must be calculated.
finalizeParam556
L (length) and CS (checksum)
POS2
POS3
POS4
POS5
POS6
POS7
