Sontex Supercom 636 - Page 33

Manual Supercom 636 R+W rev. 010312 33
For counter 2
F0 01
ID number 05 04 9E 40 lsb sb1 sb2 msb
unsigned integer (0..99999999)
Medium 05 03 A2 40 ch0 ch1 ch2 ascii char (always 3 chr complete with space ='20h')
Unit 05 05 A5 40 ch0 ch1 ch2 ch3 ch4 ascii char (always 5 chr complete with space ='20h')
Factor and initial value 05
0C
AA 40 lsb sb1 sb2 sb3 sb4 sb5 sb6 msb lsb sb1 sb2 msb
info string 05 18 B6 40 ch0 ch1 ch2 ch3 ch4 ch5 ch6 ch7 ch8 ch9
ch10
ch11
ch12
ch13
ch14
ch15
ch16
ch17
ch18
ch19
ch20
ch21
ch22
ch23
ascii char (always 24 chr complete with space ='20h')
FF
F0 01
05 04 08 02 00 00 00 00
05 04 1C 40 00 00 00 00
05 04 04 41 00 00 00 00
05 04 14 41 00 00 00 00
05 04 24 41 00 00 00 00
05 04 34 41 00 00 00 00
05 04 44 41 00 00 00 00
05 04 54 41 00 00 00 00
05 04 64 41 00 00 00 00
FF
F0 01
05 04 74 41 00 00 00 00
05 04 84 41 00 00 00 00
05 04 94 41 00 00 00 00
05 04 A4 41 00 00 00 00
05 04 B4 41 00 00 00 00
05 04 C4 41 00 00 00 00
05 04 D4 41 00 00 00 00
05 04 E4 41 00 00 00 00
05 04 F4 41 00 00 00 00
FF
For counter 3
F0 01
ID number 05 04 6C 40 lsb sb1 sb2 msb
unsigned integer (0..99999999)
Medium 05 03 70 40 ch0 ch1 ch2 ascii char (always 3 chr complete with space ='20h')
Unit 05 05 73 40 ch0 ch1 ch2 ch3 ch4 ascii char (always 5 chr complete with space ='20h')
Factor and initial value 05
0C
78 40 lsb sb1 sb2 sb3 sb4 sb5 sb6 msb lsb sb1 sb2 msb
info string 05 18 84 40 ch0 ch1 ch2 ch3 ch4 ch5 ch6 ch7 ch8 ch9
ch10
ch11
ch12
ch13
ch14
ch15
ch16
ch17
ch18
ch19
ch20
ch21
ch22
ch23
ascii char (always 24 chr complete with space ='20h')
FF
F0 01
05 04 0C 02 00 00 00 00
05 04 20 40 00 00 00 00
05 04 08 41 00 00 00 00
05 04 18 41 00 00 00 00
05 04 28 41 00 00 00 00
05 04 38 41 00 00 00 00
05 04 48 41 00 00 00 00
05 04 58 41 00 00 00 00
05 04 68 41 00 00 00 00
FF
F0 01
05 04 78 41 00 00 00 00
05 04 88 41 00 00 00 00
05 04 98 41 00 00 00 00
05 04 A8 41 00 00 00 00
05 04 B8 41 00 00 00 00
05 04 C8 41 00 00 00 00
05 04 D8 41 00 00 00 00
05 04 E8 41 00 00 00 00
05 04 F8 41 00 00 00 00
FF
init. value (unsigned int)
BLOCK B
BLOCK C
BLOCK A
BLOCK B
BLOCK C
factor is a float (double IEEE754)
factor is a float (double IEEE754)
BLOCK A
init. value (unsigned int)
