16 Technical Data
Audio Specifications
SIM Card Reader
Electrical Connectors and LED
Mechanical Specification
Parameter Limit
Output level (differential) ≥4.0V
pp
Output level
(dynamic load = 32Ω)
≥2.8V
pp
Distortion at 1kHz and maximum output level ≤5%
Offset, BEARP to BEARN ±30mV
Ear-piece mute-switch attenuation ≥40dB
Ear piece model Impedance Tolerance
Dynamic ear piece [32Ω + 800µH] // 100pF ±20%
Dynamic ear piece [150Ω +800µH]//100pF ±20%
Piezo ear piece 1kΩ +60nF ±20%
Voltage type Support for 3 V and 5 V SIM cards
Plug-in power supply connector RJ11 6-way
Handset audio connector RJ9 4-way
Antenna connector FME male
RS232 serial port Sub-D socket, 9 pin
LED Green
Length 77.4mm
Width 66.4mm
Height 26.2mm
Weight <130g
