Technical Data 17
Environmental specifications
Certification
Operating temperature range –25°C to +55°C
Storage temperature range –40°C to +85°C
Relative humidity 5 - 95%, non-condensing
Stationary vibration,
sinusoidal
Displacement: 7.5mm
Acceleration amplitude: 20m/s² and 40m/s²
Frequency range: 2-8Hz, 8-200Hz, 200-500Hz
Stationary vibration, random Acceleration spectral density (m²/s²):
0.96, 2.88, 0.96
Frequency range:
5-10Hz, 10-200Hz, 200-500Hz, 60min/axis
Non-stationary vibration,
including shock
Shock response spectrum I, peak acceleration:
3 shocks in each axis and direction; 300m/s², 11ms.
Shock response spectrum II, peak acceleration:
3 shocks in each axis and direction; 1000m/s², 6ms.
Bump Acceleration: 250m/s²
Free fall transportation 1.2m
Rolling pitching
transportation
Angle: ±35degrees; period: 8s
Static load 10kPa
Low air pressure/high air
pressure
70kPa/106kPa
Directive
1999/5/EC
EMC: EN 301 489-1
EMC: EN 301 489-7
Safety: EN 60950
GSM 3GPP TS 51.010-1
TestedaccordingtoGCF-CC
