Component Replacement (elect)
1246-2438 Rev 1
Sony Ericsson Mobile Communications AB – Company Internal
Repair Actions: Additional Repair Info
13
X3801
Protect the Coax connector with capton tape!
14
X5100
Protect the Vibrator, BtB connector and the ZIF
connector with capton tape!
15
X5101
Protect the Vibrator, the white LED and the SIM
connector with capton tape!
16
X5401
Protect the SIM connector with capton tape!
To Next Page
