Sony Ericsson Z1 - Page 4

Component Replacement (elect)
1246-2438 Rev 1
 Sony Ericsson Mobile Communications AB – Company Internal
4(17)
Position
Component
Part no.
Comments
B5000
B5002
B5003
B5500
B5501
Vibrator Bar Analog DC
IC
IC
Microphone
Microphone
1204-8172
1220-4770
1220-4470
1210-7410
1210-7410
P BGA  1
S HA  20
S HA
P BGA  2
S BGA
C5200
C5606
C5613
Capacitor 1.0 uF +/-10% 25.0 V K0603
Capacitor 1.5 nF +/-10% 50.0 V K0402
Capacitor Ceramic 4,7 uF +/-20% 25, V 08
1000-0076
1000-6548
1220-2537
S HA
S HA
S HA
E1000
Shield Can Closed Drawn Can - RF
1233-5273
S BGA
L3900
L3901
L3902
L3903
L3904
L4001
L5402
L5403
L5503
L5504
L5505
L5506
L5507
L5508
L5600
L5601
Ind WW 2.2 uH
Ind Chip 2.2 uH +/- 20% K0805
Ind WW 2.2 uH
Ind WW 2.2 uH
Ind WW 2.2 uH
Ind WW 2,2 uH +/-20% K3012
Filter
Filter
Filter 0.0 Hz 0402
Filter 0.0 Hz 0402
Filter 0.0 Hz 0402
Filter 0.0 Hz 0402
Filter 0.0 Hz 0402
Filter 0.0 Hz 0402
Ind WW 10, uH
Ferrite B 240.0 Ohm 200.0 mA 0201
1232-8769
1234-7293
1232-8769
1232-8769
1232-8769
1223-4064
1000-2609
1000-2609
1200-0317
1200-0317
1200-0317
1200-0317
1200-0317
1200-0317
1000-3331
1000-2593
S HA
S HA
S HA
S HA
S HA
S HA
S HA
S HA
P HA  3
P HA  3
P HA  3
S HA  4
S HA  4
S HA  4
S HA
S HA
N1200
N1200
N1600
N1600
N1700
N1701
N1800
N1902
N2100
N2500
N2501
N3802
N3803
N4003
N4400
N4401
N4402
N4500
N4700
N4800
N4801
N4802
N5200
N5300
N5301
ASIC RF Transceiver 308 NSP
ASIC RF Transceiver QTR-8200 308-NSP
Mod PA WCDMA 3X3X1 824-849MHz - REX-Q
Mod PA WCDMA 3X3X1 880-915MHz
Mod PA WCDMA 3X3X1 1920-1980MHz - REX-Q
Mod PA WCDMA 3X3X1 1850-1910MHz - REX-Q
Mod PA QUAD GSM850/GSM900/DCS/EDGE
RF Antenna Switch GSM & UMTS/CDMA DUAL
IC Amp 1010x0.4
Mod BB WLAN 6.57 x 5.62 x 0.55mm
IC Switch 2x2x0.6 mm, 8pin
IC Lin TDFN-8
IC Lin WDFN6 Protection Interface Circui
IC Lin Converter Step Down
IC Dri WL-CSP 2x1.5 4x3 balls, 0.5mm pit
IC ESD Prot Micro QFN 16L 3,3x1,5mm
IC ESD Prot Micro QFN 16L 3,3x1,5mm
IC Vreg PLP1010-4
IC Switch UMLP-28 Dual Row (3.6X2.8mm) I
IC ESD Prot 2.50x1.20x0.50mm
IC ESD Prot 2.50x1.20x0.50mm
IC ESD Prot 2.50x1.20x0.50mm
IC ESD Prot
IC Amp CSP-9 Class D Mono
IC Amp CSP-9 Class D Mono
1228-1206
1228-2273
1238-0476
1238-0477
1238-0469
1238-0474
1232-2928
1237-2994
1232-9070
1227-7418
1239-0547
1221-6812
1228-1705
1227-6376
1219-2970
1225-4036
1225-4036
1201-6465
1228-8877
1227-5811
1227-5811
1227-5811
1227-8675
1237-8660
1237-8660
S BGA C CDMA Only
S BGA C All Band
(Not CDMA)
S HA C For Band 5
S HA C For Band 8
S HA C All Band
(Not CDMA)
S HA C For Band 2
S BGA C All Band
(Not CDMA)
S HA C All Band
P HA
S BGA
S HA
S HA
S HA
S HA
S HA
S HA  5
S HA  5
S HA
S HA
S HA
S HA
S HA  6
S HA
S HA
S HA
