Sony Ericsson Z1 - Page 5

Component Replacement (elect)
1246-2438 Rev 1
 Sony Ericsson Mobile Communications AB – Company Internal
5(17)
Position
Component
Part no.
Comments
N5400
N5500
N5600
N5701
ASIC Tjatte3 CSP20
IC Amplifier 500mA
IC WL-CSP 6x4 balls
MEMS Compass Analog
1000-0198
1203-4594
1212-7979
1228-7182
S HA
S HA  6
S HA
S HA
S4803
S4804
S4805
S4806
S4807
S4808
S4809
S4810
S5000
S5001
S5002
S5003
S5004
S5005
S5006
S5007
Input Switch
Input Switch
Input Switch Other TACT SWITCH 3.7 x 3.7
Input Switch Other TACT SWITCH 3.7 x 3.7
Input Switch
Input Switch Side Push/
Input Switch Side Push/
Input Switch Other TACT SWITCH 3.7 x 3.7
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
Input Switch Other TACT SWITCH
1001-0060
1001-0060
1213-3638
1213-3638
1001-0060
1245-9546
1245-9546
1213-3638
1230-4023
1230-4023
1230-4023
1230-4023
1230-4023
1230-4023
1230-4023
1230-4023
P HA/ST
P HA/ST
S HA
S HA
S HA/ST
P HA/ST  19
P HA/ST  21
S BGA
S HA/ST
S HA/ST
S HA/ST
S HA/ST
S HA/ST
S HA/ST
S HA/ST
S HA/ST
V3801
V3802
V3803
V4400
V4802
V5000
V5100
V5102
V5300
V5301
V5500
V5600
ZenerDiode, 5.6V, Pb-free
ZenerDiode, 5.6V, Pb-free
Trans N-ch FET 1.2X0.8X0.5
LED White 2.04x1.64x0.7mm
LED RED/GREEN/BLUE
Diode Schottky 20.0 V SOD323
Diode Protection 5, V SOD-923
Trans P-ch FET WDFN6
Diode Zener 5.0 V SOT-723
Diode Zener 5.0 V SOT-723
Diode Zener 5.0 V SOT-723
MOSFET & Schottky Diode
1001-1864
1001-1864
1200-2023
1228-6212
1200-1926
1200-1679
1201-8440
1200-1780
1203-0201
1203-0201
1203-0201
1201-3866
S HA
S HA
S HA
P BGA  7
S HA/ST  8
P HA  9
S HA
S HA
S HA
S HA
S HA
S HA
W2100
Internal Antenna Connector
1000-0308
P HA
X1900
X1901
X2500
X2501
X3801
X4300
X4500
X5000
X5100
X5101
X5200
X5401
Conn Coax Receptacle 0p test switch
Conn Pogopin 2p
Conn Coax Receptacle 0p test switch
Conn Leaf Spring Receptacle 1p
Conn Pogopin Plug 5p
Conn BtB Receptacle 64p
Conn BtB Receptacle 30p Hirose DF37B
Conn FPC Receptacle 8p
Card Conn SIM push-pull w/switch
Connector BtB
Conn USB micro B Receptacle 5p mid-mount
CONNECTOR/5 POS/FPC
1221-6477
1233-8058
1221-6477
1200-2144
1226-6294
1231-1872
1216-9089
1232-9797
1227-3532
1202-0859
1232-9759
1001-6666
P BGA  10
P BGA  11
P BGA  12
P HA  17
P BGA  13
S BGA
S BGA
S BGA
P BGA  14
P BGA  15
S BGA
P BGA  16
Z2100
Z2101
Z2500
Z4300
Z4301
Z4302
Z5200
Filter 1.575 GHz
Filter SAW 1.575 GHz
Filter Cer RF 2.45 GHz Bluetooth/W-LAN
Filter 100.0 MHz
Filter 100.0 MHz
Filter 100.0 MHz
Filter 100.0 MHz
1236-2944
1211-5714
1228-7102
1224-6060
1224-6060
1224-6060
1224-6060
S HA
P HA
S HA
S HA  18
S HA  18
S HA  18
S HA
