Sony a65 - Rear Side

SLT-A65/A65V
4-287-953-11(1)
G:\Works\CX86800\DTP\IM\4287953111\4287953111SLTA65A65VU2\01GB-
SLTA65A65VU2\030GET.fm
Master: Left
14
Identifying parts
A Eyepiece sensors
B Viewfinder*
• When you look into the
viewfinder, the viewfinder
mode is activated, and when
you take your face away from
the viewfinder, the screen mode
returns to the LCD monitor
mode.
C Diopter-adjustment dial (29)
D LCD monitor (73)
E Light sensor
F Eyecup
G For shooting: Fn (Function)
button (53, 54)
For viewing: (Image
rotation) button (52)
H Control button
v/V/b/B/DISP (Display) (52)/
WB (White balance) (52)/
(Drive) (45, 52)/
(Picture Effect) (52)
I Control button (Enter)/AF
button (52)/Object Tracking
button (52)
J (In-Camera Guide) button
(63)
For viewing: (Delete) button
(34)
K (Playback) button (33)
* Do not directly touch this
part.
Rear side
