Specifications
GB
50
[Power consumption]
When using a DT 16-50 mm F2.8
SSM*
When using the viewfinder:
Approx. 3.5 W
When using the screen:
Approx. 3.0 W
* Supplied with ILCA-77M2Q.
[Others]
Microphone: Stereo
Speaker: Monaural
Exif Print: Compatible
DPOF: Compatible
PRINT Image Matching III:
Compatible
Dimensions:
142.6 mm × 104.2 mm ×
80.9 mm (5 5/8 inches ×
4 1/8 inches × 3 1/4 inches)
(W/H/D, excluding protrusions)
Mass:
Approx. 726 g (1 lb 9.6 oz) (with
battery and Memory Stick PRO
Duo media)
Approx. 647 g (1 lb 6.8 oz) (body
only)
Operating temperature: 0°C to 40°C
(32°F to 104°F)
[Wireless LAN]
Supported format: IEEE 802.11 b/g/n
Frequency band: 2.4 GHz bandwidth
Security: WEP/WPA-PSK/WPA2-
PSK
Connection method: WPS (Wi-Fi
Protected Setup)/Manual
Access method: Infrastructure mode
NFC: NFC Forum Type 3 Tag
compliant
Design and specifications are
subject to change without notice.
Battery charger/Battery
BC-VM10A Battery charger
Input rating: 100 V - 240 V AC,
50/60 Hz, 9 W
Output rating: 8.4 V DC, 0.75 A
Operating temperature range:
0°C to 40°C (32°F to 104°F)
Storage temperature range:
–20°C to +60°C (–4°F to +140°F)
Maximum dimensions:
Approx. 70 mm × 25 mm ×
95 mm (2 7/8 inches × 1 inch ×
3 3/4 inches) (W/H/D)
Rechargeable battery pack
NP-FM500H
Battery type: Lithium-ion battery
Maximum voltage: DC 8.4 V
Nominal voltage: DC 7.2 V
Maximum charge voltage: DC 8.4 V
Maximum charge current: 2.0 A
Capacity:
Typical: 11.8 Wh (1 650 mAh)
Minimum: 11.5 Wh (1 600 mAh)
Maximum dimensions:
Approx. 38.2 mm × 20.5 mm ×
55.6 mm (1 9/16 inches ×
13/16 inches × 2 1/4 inches)
(W/H/D)
