Sony AVD-S50 - Page 96

12
FR
Panneau arrière
COAXIAL
OUT IN
OUT
ANALOG
FRONTCENTER
AM
L
R
FM
75Ω
ANTENNA
SPEAKERS
IMPEDANCE USE 6–16Ω
SUB
WOOFER
OUT
OPTICAL
1
OPT IN
2
OPT IN
3
COAX IN
ANALOG DIGITAL
LR
SURROUND
LR
+
–
EURO AV OUTPUT(TO TV) EURO AV INPUT(FROM VIDEO)
1 Antenne AM (20)
2 Prise T EURO AV OUTPUT (TO TV)
(22)
3 Prise t EURO AV INPUT (FROM
VIDEO) (23)
4 Prises SPEAKERS (enceintes) (18)
5 Prise SUB WOOFER (ANALOG OUT)
(18)
6 Prise DIGITAL (COAX IN 3)
7 Prise DIGITAL (OPT IN 2)
8 Prise DIGITAL (OPT IN 1)
9 Prise DIGITAL (OPTICAL OUT)
0 Prises ANALOG IN/OUT L/R
qa Prise d’antenne FM 75Ω COAXIAL
(sortie FM coaxiale 75Ω) (20)
