Sony BDV-L600 - Specifications

78
GB
Specifications
Amplifier Section
POWER OUTPUT (reference)
Subwoofer: 120 W (at 4 ohms, 80 Hz)
BDV-L800/BDV-L800M:
POWER OUTPUT (rated)
Front L/Front R: 85 W + 85 W (at 4 ohms,
1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R: 130 W (per channel at
4 ohms, 1 kHz)
BDV-L600:
POWER OUTPUT (rated)
Front L/Front R: 80 W + 80 W (at 4 ohms,
1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R: 115 W (per channel at
4 ohms, 1 kHz)
Inputs (Digital)
TV (Audio Return Channel/OPTICAL)
Supported formats: LPCM
2CH (up to 48 kHz), Dolby
Digital, DTS
HDMI IN 1/HDMI IN 2 Supported formats: LPCM
2CH (up to 96 kHz), Dolby
Digital, DTS
Video Section
Outputs VIDEO: 1 Vp-p 75 ohms
HDMI Section
Connector Type A (19pin)
BD/DVD/Super Audio CD/CD System
Signal format system NTSC/PAL
USB Section
(USB) port: Type A (For connecting
USB memory, memory
card reader, digital still
camera, and digital video
camera)
LAN Section
LAN(100) terminal 100BASE-TX Terminal
Wireless LAN Section
BDV-L800/BDV-L800M
Standards Compliance IEEE 802.11 b/g/n
Frequency and Channel 2.4 GHz - 2.4835 GHz
[CH1 -13]
FM Tuner Section
System PLL quartz-locked digital
synthesizer
Tuning range 87.5 MHz - 108.0 MHz (50
kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 250 kHz/300 kHz/
350 kHz/400 kHz
General (Main Unit, AC Adapter (AC-
BD100))
Power requirements (AC Adapter)
Input: 110 V - 240 V AC,
50/60 Hz
Output: 14 V DC, 3.3 A
Operating Temperature:
40 °C (MAX)
Power consumption On: 30 W
Standby: 0.3 W (at the
Power Saving mode)
Dimensions (approx.)
AC Adapter 122 mm × 37 mm × 64 mm
(w/h/d)
Main Unit 480 mm × 46 mm × 232
mm (w/h/d)
480 mm × 259 mm × 103
mm (w/h/d) (with stand)
480 mm × 105 mm × 231
mm (w/h/d) (in a
horizontal position)
Mass (approx.)
AC Adapter 0.3 kg
Main Unit L800: 3.2 kg
4.2 kg (with stand)
L800M: 3.3 kg
4.3 kg (
with stand)
L600: 3.0 kg
4.0 kg (with stand)
Speakers
Front Speaker (SS-TSL800) for BDV-L800/
BDV-L800M
Speaker system 2-Way 2-Driver Speaker
system
Speaker unit Tweeter: 25 mm dome
type
Full range: 65 mm cone
type
Rated impedance 4 ohms
Dimensions (approx.) 123 mm × 475 mm × 137
mm (w/h/d)
Mass (approx.) 1.3 kg
Front Speaker (SS-TSL600) for BDV-L600
Speaker system 2-Way 2-Driver Speaker
system Bass reflex
Speaker unit Tweeter: 25 mm dome
type
Full range: 50 mm cone
type
Rated impedance 4 ohms
