2
Ground wire (for SDI
module)
Ground wire (with
faston connector, for
BB board)
To prevent fire or shock hazard, do
not expose the unit to rain or mois-
ture.
The component SDI kit <VIDEO> BKM-
101C is designed to be installed into a
monitor alone. It can also be installed
together with the component SDI kit
<AUDIO> BKM-102.
This Installation Manual explains how to
install BKM-101C and BKM-102.
WARNING
BKM-101C
Spacer*
(with adhesive tapes)
BB board
3-pin connecting cable
(Type A: One end is
shielded.)*
12-pin connecting
cable*
3-pin connecting cable
(Type B: Both ends
have connectors.)
* These parts are not used in the monitors shown
on the cover page.
Parts List
Parts List
Continue
SDI module
Connector label Adaptor fitting for
20-inch monitor
Screw
+BVTT 4 × 8
× 5
Cable clamp
(black)
IN
OUT
COMPONENT SDI
ACTIVE THROUGH
Connecting cables
Holder
(for 14-inch
monitors)
× 1
Ferrite core (small)
BKM-102
BA board 5-pin connecting cable
4-pin connecting
cable
30-pin flat cable
Screw +BVTP 3× 8
× 4
Ferrite core (large)
Cable clamp (ø11)
Screw
+PS 4 × 8
× 1
× 1
× 2
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 2
× 1
× 1
× 1
× 1
× 1
English
To Next Page
