TRIMASTER EL OLED Master Monitor
For Critical Picture Evaluation
BVM-E250 BVM-F250BVM-E170 BVM-F170
The groundbreaking BVM E series and BVM F series are reference monitors,
using the Sony OLED system and incorporating leading-edge technologies
to bring out the full performance capabilities required for critical picture
evaluation, where accuracy is everything.
The Sony OLED uses the Sony Super Top Emission technology with 10-bit RGB panels and OLED processing
Professional display engine
• Nonlinear Cubic Conversion color management system
• Cutting-edge interlaced to progressive conversion technology with extremely low process delay
• 12-bit output accuracy signal processing
Input versatility
• Standard Input: 3G/HD/SD-SDI (x2) (selectable input), HDMI (HDCP) (x1), DisplayPort (x1)*
1
• Four option slots for input expansion: Six optional BKM boards are available for different needs
Leading-edge features
• Interlace Display, HD Frame Capture, Pixel Zoom, P&P (Side-by-side, Butterfly*
2
, Wipe*
2
, Blending*
2
)
Cinema features (BVM-E Series only)
• Wide color gamut: D-Cine conforming to DCI-P3, BVM Native offering the widest color gamut
• High frame rate: 24P/PsF, 2P/PsF are displayed at 72 Hz and 7 Hz respectively
• 2K Cinema formats with multiple display modes
(Full image display, or Native pixel-to-pixel display with an Image-slide function)
• ASC CDL (American Society of Cinematographers Color Decision List)*
1
and User LUT*
1
Auto white adjustment with PC application software*
1
3D signal analysis (as a 2D monitor) with optional BKM-20TG 3G-SDI input adaptor
Closed caption display with optional BKM-244CC HD/SD-SDI closed caption adaptor
*1 Available from firmware V1.1 or later.
*2 BVM-E Series only.
BVM-E Series BVM-F Series
