27
BVM-E / BVM-F Series HDMI Input Signal Formats
System
Interface sampling freq
(MHz)
Aspect Ratio Standard
HDMI
RGB 4:4:4 8/10/12 bit
Y/C
B/CR 4:4:4 8/10/12 bit
Y/C
B/CR 4:2:2 12 bit
Viedo Signals
640 x 480/60p* 25.200* 4:3
CEA-861
O
720 x 480/60p* 27.027* 4:3/16:9 O
1280 x 720/60p* 74.250* 16:9 O
1920 x 1080/60i* 74.250*
16:9 CEA-861
O
2.39:1
720 (1440) x 480/60i* 27.027* 4:3/16:9
CEA-861
O
720 x 576/50p 27.000* 4:3/16:9 O
1280 x 720/50p 74.250 16:9 O
1920 x 1080/50i 74.250
16:9 CEA-861
O
2.39:1
720 (1440) x 576/50i 27.000 4:3/16:9 CEA-861 O
1920 x 1080/60p* 148.500*
16:9 CEA-861
O
2.39:1
1920 x 1080/50p 148.500
16:9 CEA-861
O
2.39:1
1920 x 1080/24p* 74.250*
16:9 CEA-861
O
2.39:1
1920 x 1080/25p 74.250
16:9 CEA-861
O
2.39:1
1920 x 1080/30p* 74.250*
16:9 CEA-861
O
2.39:1
Computer Signals
800 x 600/60p 40.000 4:3
VESA
O
1024 x 768/60p 65.000 4:3 O
1280 x 960/60p 108.000 4:3 O
1280 x 1024/60p 108.000 5:4 O
1400 x 1050/60p 121.750 4:3 O
fH: 28-75 kHz, fV: 48-85 Hz
Max. res.: 1920 x 1080/60p
25.000-162.000
* Also compatible with 1/1.001 frame rates.
PVM-2541 / PVM-1741 / PVM-740 Signal Formats
System
Signal standard
Analog composite
SDI (3G/HD/SD)
HDMI
PVM-2541 / PVM-1741 PVM-740
575/50i (PAL) O O O O
480/60i (NTSC)*
1
O O O O
576/50p – – – O
480/60p*
1
– – – O
640 x 480/60p*
1
– – – O
1080/24PsF*
1
*
2
– O*
3
O –
1080/25PsF*
2
– O*
3
O –
1080/30PsF*
1
*
2
– O*
3
– –
1080/24p*
1
– O*
3
O O
1080/25p – O*
3
O O
1080/30p*
1
– O*
3
O O
1080/50i – O*
3
O O
1080/60i*
1
– O*
3
O O
1080/50p – O*
4
O*
4
O*
6
1080/60p*
1
– O*
4
O*
4
O*
6
720/24p*
1
– O*
5
– –
720/25p – O*
5
– –
720/30p*
1
– O*
5
– –
720/50p – O*
3
O O*
6
720/60p*
1
– O*
3
O O*
6
*1 Compatible with 1/1.001 frame rates.
*2 1080/24PsF, 2PsF, and 30PsF are displayed as 1080/48i, 0i, and 60i on the screen, respectively.
*3 10-bit 4:4:4 Y/C
B/CR and 4:4:4 RGB of 3G-SDI signals are supported.
*4 10-bit 4:2:2 Y/C
B/CR of 3G-SDI signal is supported.
* 10-bit 4:4:4 Y/C
B/CR of 3G-SDI signal is supported.
*6 PVM-241 and PVM-1741 can accept DVI signals via the HDMI interface using a conversion cable.
