Dimensions
41
Dimensions
Front
Rear
To install on a vehicle, fix the unit using screw holes for
the YOKE mount.
Side
Unit: mm (inches)
Mass:
Approx. 16.0 kg (35 lb 4.4 oz)
Unit: mm (inches)
6-M4 hole
6-M4 hole
(for the YOKE mount)
* Length of M4 screws (rear)
Monitor cabinet
Attached object
6 (
1
/
4
) to 7 (
9
/
32
)
M4 screw
