MAINTENANCE Menu
Menu Page Items: default setting Setting values
<AUTO SETUP> M1 AUTO BLACK
AUTO WHITE
AUTO LEVEL
AUTO WHITE SHADING
AUTO BLACK SHADING
TEST SIGNAL : OFF OFF/TEST1/TEST2
<GENLOCK>
(effective in the
standalone operation
only)
M2 H PHASE [COARSE] : 0 –99 to +99
[FINE] : 0 –99 to +99
SC PHASE : 0 –99 to +99
GENLOCK : ENABLE ENABLE/DISABLE
VF VIDEO : NORMAL NORMAL/GENLOCK
<FORMAT> M3 FORMAT : 59.94I NTSC: 59.94I/29.97PsF, PAL: 50I/25PsF
PsF-SHUTTER LINK : OFF ON/OFF
CROP : OFF (16:9) OFF (16:9)/ON (4:3) (BVP-E30WS/
E30WSP only)
<AUTO IRIS> M4 WINDOW : 1 1/2/3/4/5/6
OVERRIDE : 0 –99 to +99
IRIS LEVEL : 0 –99 to +99
APL RATIO : 80 –99 to +99
IRIS GAIN : 0 –99 to +99
AUTO IRIS : ON ON/OFF
<WHITE SHADING> M5
V SAW
[R] [G] [B] [M]
: 0 0 0 0 –99 to +99
V PARA : 0 0 0 0 –99 to +99
H SAW : 0000 –99 to +99
H PARA : 0 0 0 0 –99 to +99
WHITE : 0 0 0 0 –99 to +99
AUTO WHITE SHADING
WHITE SHAD MODE : RGB RGB/RB
3D WHITE SHAD : ON ON/OFF
<BLACK SHADING> M6
V SAW
[R] [G] [B] [M]
: 0 0 0 0 –99 to +99
V PARA : 0 0 0 0 –99 to +99
H SAW : 0000 –99 to +99
H PARA : 0 0 0 0 –99 to +99
BLK SET : 0 0 0 0 –99 to +99
BLACK : 0000 –99 to +99
MASTER GAIN : 0dB –3/0/3/6/9/12/18/24/30/36/42
AUTO BLACK SHADING
2D BLACK SHAD : ON ON/OFF
<ENCODER> M7 CHU COLOR BARS : OFF ON/OFF
CB MODE : SMPTE (NTSC)/
FULL(75%) (PAL)
SMPTE/EIA/FULL(75%)/FULL(100%)
(NTSC;SMPTE/PAL;FULL(75%) standard)
Q-FILTER : WIDE NORMAL/WIDE (NTSC only)
