– 45 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R201 1-249-421-11 CARBON 2.2K 5% 1/4W
R202 1-249-441-11 CARBON 100K 5% 1/4W
R203 1-249-421-11 CARBON 2.2K 5% 1/4W
R204 1-249-428-11 CARBON 8.2K 5% 1/4W
R205 1-249-429-11 CARBON 10K 5% 1/4W
R206 1-249-441-11 CARBON 100K 5% 1/4W
R207 1-249-421-11 CARBON 2.2K 5% 1/4W
R301 1-249-425-11 CARBON 4.7K 5% 1/4W
R302 1-249-429-11 CARBON 10K 5% 1/4W
R303 1-249-417-11 CARBON 1K 5% 1/4W
R304 1-249-417-11 CARBON 1K 5% 1/4W
R305 1-247-807-31 CARBON 100 5% 1/4W
R306 1-249-437-11 CARBON 47K 5% 1/4W
R307 1-249-413-11 CARBON 470 5% 1/4W
R308 1-249-413-11 CARBON 470 5% 1/4W
R309 1-249-413-11 CARBON 470 5% 1/4W
R310 1-249-413-11 CARBON 470 5% 1/4W
R311 1-249-425-11 CARBON 4.7K 5% 1/4W
R312 1-249-429-11 CARBON 10K 5% 1/4W
R313 1-249-393-11 CARBON 10 5% 1/4W
R314 1-249-429-11 CARBON 10K 5% 1/4W
R315 1-249-393-11 CARBON 10 5% 1/4W
R316 1-249-429-11 CARBON 10K 5% 1/4W
R317 1-249-425-11 CARBON 4.7K 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R319 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
* A-4699-278-A PANEL BOARD, COMPLETE
**********************
< CONNECTOR >
* CN601 1-568-852-11 SOCKET, CONNECTOR 9P
< LED >
D601 8-719-032-86 LED SEL5420E (DISC 1)(GREEN)
D602 8-719-032-86 LED SEL5420E (DISC 2)(GREEN)
D603 8-719-032-86 LED SEL5420E (DISC 3)(GREEN)
D604 8-719-032-98 LED SEL5820A (DISC 1)(AMBER)
D605 8-719-032-98 LED SEL5820A (DISC 2)(AMBER)
D606 8-719-032-98 LED SEL5820A (DISC 3)(AMBER)
< RESISTOR >
R602 1-216-041-00 METAL CHIP 470 5% 1/10W
R603 1-216-045-00 METAL CHIP 680 5% 1/10W
R604 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R605 1-216-052-00 METAL CHIP 1.3K 5% 1/10W
R606 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R611 1-216-025-00 METAL GLAZE 100 5% 1/10W
R612 1-216-025-00 METAL GLAZE 100 5% 1/10W
R613 1-216-025-00 METAL GLAZE 100 5% 1/10W
R614 1-216-025-00 METAL GLAZE 100 5% 1/10W
R615 1-216-025-00 METAL GLAZE 100 5% 1/10W
R616 1-216-025-00 METAL GLAZE 100 5% 1/10W
R625 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
< SWITCH >
S601 1-762-196-21 SWITCH, TACT (EX-CHANGE)
S602 1-762-196-21 SWITCH, TACT (SKIP)
S603 1-762-196-21 SWITCH, TACT (DISC 1)
S604 1-762-196-21 SWITCH, TACT (DISC 2)
S605 1-762-196-21 SWITCH, TACT (DISC 3)
S606 1-762-196-21 SWITCH, TACT (§ OPEN/CLOSE)
************************************************************
* 1-663-324-11 RELAY BOARD
***********
< CONNECTOR >
CN701 1-695-088-11 PIN, CONNECTOR (PC BOARD) 9P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
* 1-663-322-11 SENSOR BOARD
************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* 1-663-323-11 TABLE BOARD
***********
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
MAIN PANEL RELAY SENSOR TABLE
To Next Page
